Cortex SM20 - STEP 7

17ASSEMBLY INSTRUCTIONS |
1. Install (#38) to (#7) as shown and secure with bolts (#61) and flat spacers (#63). Then insert (#47)
onto (#38).
2. Attach (#32), (#35), and (#36) to (#6) and repeat on the other side.
Tighten all bolts with a Wrench.
1. Your device is now fully assembled.
2. Please check that all pulleys and wire ropes have been secured before proper use.
3. Adjust the wire rope according to your exercise.
STEP 7
47
38
63
61
41
40
37
36
32
35
39
34
33
