13ASSEMBLY INSTRUCTIONS |
After the whole device is assembled, check if the wire rope needs tightening. If the wire rope is slightly
loose, adjust by tightening the lower bolts of the high pull wire rope (#22-1).
If the rope is loose, adjust the pulley mounting hole adjustment through the pulley adjustment (#53-2).
Be sure to insert the wire rope first and then install the pulley.
STEP 5
22-1
22-3
53-4
22-2
53-2
