BEFORE MAKING THE ELECTRICAL CONNECTION, MAKE SURE THAT:
• The safety circuit-breaker and the electrical system are able to with stand the load of the
appliance. See rating label on back of range.
• Rating plate is located on back of range should you need to verify any of the electrical
requirements.
• The power supply system has a ground connection in good working order in accordance with the
regulations in force.
• The electrical socket is easily accessible with the appliance installed. In all cases, the power
supply lead must be positioned so that it does not reach a temperature of 50
o
C above the room
temperature at any point.
• The manufacturer is not liable for any direct or indirect damage caused by faulty installation or
connection. It is therefore necessary that all installation and connection operations are carried out by
qualified personnel complying with the local and general regulations in force.
CONNECTIO
N OF THE RANGE WIRES TO THE MAINS
1) This appli
ance is equipped with the following wires:
•
One Black Wire, One Red Wire (L1 and L2 - Liv
e)
•
One Yellow /Green (Ground)
2) Follow the diagram below to know how to connect the freestanding range wires to the
electrical main wires of the home. (See Figure 24)
32
