BAFFLE FILTER INSTALLATION RECIRCULATING CHARCOAL FILTERS
Step 3: Twist and lock the filter into place.
Step 4: Repeat Steps 2-3 on the left side of the motor.
Step 5: Reinstall the ARC-FLOW Baffle Filters back into place.
NOTE: Chimney vent holes must be open
and visible for the filtered air to
recirculate.
Chimney
vent holes
MOTOR
Step 1: Remove the ARC-FLOW Baffle Filters.
Step 2: Locate the motor (pictured below) and align one of the filters with the right side of the motor.
It is recommended that the charcoal filter be replaced every 4-6 months. Charcoal filter replacements
are available for purchase at: www.cosmoappliances.com. Charcoal Filter Kit Part# CFK1-TM or
CFK6 (COS-6324EWH Model Only)
SCAN QR CODE
FOR INSTALLATION
VIDEO
