Cosmo PDC 400 User Manual

Pendular Spreader PDV-PDHV models
31
MOD. PDHV 800/1000/1250 TELAIO
MOD. PDHV 800/1000/1250
COMPLETE FRAME
Codice
Code
QT. REF. DESCRIZIONE DESCRIPTION
613.111 1 1 Telaio completo mod.PDV600
Complete frame PDV600 model
602.008 2 2/4 Bacchetta anteriore lunga
Long front rod
602.009 2 3/5 Bacchetta posteriore corta
Short back rod
635.014 1 6 Tubo rettangolare supporto tramoggia
Rectangular tube for hopper support
637.001 1 7 Barra sollevamento diritta
Right hook up bar
637.002 1 8 Barra sollevamento sagomata-optional
Shaped hook up bar
300.045 2 9 Vite TE 12x50 Screw Hexagonal-Head 12x50
300.044 8 10 Vite TTQST 10x30
Screw Round-Head 10x30
303.025 8 11 Rondella 10x30 Washer 10x30
300.017 2 12 Vite TE 10x35 Screw Hexagonal-Head 10x35
300.049 3 13 Vite TTQST 10x70
Screw Round-Head 10x70
303.008 4 14 Rondella 12x24 Washer 12x24
301.013 5 15 Dado aut.alto M10
Self locking nut M10
301.000 4 16 Dado medio M12
Nut M12
301.010 8 17 Dado medio M10
Nut m10
303.015 11 18 Rondella 10x20 Washer 10x20
612.003 2 19 Tappo in plastica
Plastic cap
609.051 1 22 Tramoggia PDV800
Hopper PDV800
609.053 1 23 Rialzo PDV1000 Extension PDV1000
609.054 1 24 Rialzo PDV1250 Extension PDV1250
300.057 4 25 Vite TTQST 10X80
Screw Round-Head 10x80
301.010 4 26 Dado medio M10
Nut M10
634.001 2 28 Gancio attacco Connection hook
