Pendular Spreader PDV-PDHV models
33
RIDUTTORE MOD. PDV GEARBOX PDV MODEL
Codice
Code
REF. DESCRIZIONE DESCRIPTION
610.018 1 Piastra fissa di dosaggio Dosing plate fixed
304.037 2 Scatola protezione riduttore Cover unit
308.002 3 Adesivo orizzontale lato Decal horizontal
308.003 4 Adesivo ingrassaggio Grease decal
300.033 5 Vite testa esagonale 8.8-M14x65/DM Hexagonal head screw 8.8-M14x65/DM
300.034 6 Vite testa esagonale M5x25/rvs Hexagonal head screw M5x25/rvs
300.035 7 Vite testa esagonale M10x20/rvs Hexagonal head screw M10x20/rvs
301.046 8 Dado m10/rvs Nut m10/rvs
301.045 9 Dado m5/rvs/nylon Nut m5/rvs/nylon
301.044 10 Dado m14/rvs/nylon Nut m14/rvs/nylon
303.004 11 Rondella 5,3/rvs Washer 5,3/rvs
303.003 12 Rondella 10,5/rvs Washer 10,5/rvs
304.040 13 Coperchio foro chiave Cap adjust. hole
610.017 14 Disco di dosaggio Dosing plate adjust.
304.039 15 Anello disco di dosaggio Ring dosing plate
619.022 16 Agitatore Agitator
304.038 17 Cappuccio asse Cap of agitator axle
308.004 18 Adesivo di sicurezza Safety decal
322.090 19 Riduttore completo Complete gear box
