Costco 2127014 - Step 1: Post Assembly; Attach Base Plate to Post; Insert Post Cover; Connect Top Cover to Post

Step 1
Fig 1
A
AA
I
AA
H
Fig 1
Fig 2
Fig 3
A
A1
Fig 2
AA
AA
A
A
A
AA
B
B
B
Fig 3
A
B
A1
I
1.1. Insert the Base Cover (I) into the bottom post, connect the Base Plate (H) to the Post (A) with
Bolt (AA), as seen in Fig 1;
1.2. Insert the Post Cover (A1) from the top of the post, as seen in Fig 2;
1.3. Connect the Top Cover (B) to the Post (A) with Bolt (AA), as seen in Fig 3.
Ax4 A1x4 Bx4 Hx4 Ix4
AAx20
-07-
