Costco 2127014 - Step 2: Long Lintels Assembly; Connect Long Lintels and Lintel Cover; Attach Long Netting Tube

Step 2
C4
D2
D2
C3
AA
CC
C4
HH
HH
HH
C3
C4
D
D
AA
CC
C4
C3
Fig 4.2
Fig 4.1
Fig 4.3
2.1 Connect the Right Long Lintel (C4) and the Left Long Lintel (C3) with the Connector (D)
and Bolt (AA), with Bolt (CC) at the top of the lintel, fix the Lintel Cover (F2) at the same time,
as seen in Fig 4.1-Fig 4.4;
2.2 Connect
Long Netting Tube (D2) to Lintel (C3/C4), and fix them with Bolt (HH)，as seen in Fig 4.5.
CC
C4
C3
Fig 4.4
Fig 4.5
CC
F2
C3x2
C4x2
Dx2 D2x4
F2x2
AAx16 CCx8 HHx12
C3/C4
D2
