Costco Vitis - Assembly Steps; Step 1: Attach Base Plates to Posts

A1/A2
H
G
1. Slide the Base Cover (H) over the Post (A1/A2),
then attach the Base Plate (G) to the
Posts (A1/A2) with Bolts (EE). See Fig.1
Step 1
A1/A2
H
EE
EE
G
A1*2
Fig.1
A2*2 G*4 H*4 EE*8
-5-
