Costco Vitis - Step 3: Assemble Lower Lintels

Step 3
C1
I
K1
C2
3. Insert one end of the Connector (I) into the Lower Lintel (C1) with Bolt (AA) and please
don't tighten it, then put on the Shield (K), insert the other end into the Lower Lintel (C2)
with Bolt (AA), see Fig.4
Tighten all bolts now.
AA
C1
I
K1
C2
AA
C1
K1
I
C2
AA
C1 K1 C2
Fig.4
C1*2 C2*2
I*2 K1*2 AA*8
