Troubleshooting guide
Trouble Possible cause Action
The eng-
ine does
notstart.
Low engine
output.
The engine
runs
erratically.
Insufficient
compression.
Loose sparkplug. Tighten.
Loose cylinder headbolt. Tighten.
Damaged cylinder head gasket. Replace gasket.
Sufficient
compression.
Fuel system
problem: no
fuel supplied
to combustion
chamber.
Starter handle pulled too slowly.
Pull starter handle
more sharply.
Foreign matter intank. Clean thetank.
Clogged fuelline. Clean thefuelline.
Fuel tankempty. Addfuel.
Fuel cut-off valve or air vent closed. Open.
Electrical system
problem: fuel
supplied to
combustion
chamber.
Insufficient
spark.
Spark plug dirty
orwet.
Clean.
Faulty sparkplug. Change sparkplug.
Faulty magnet.
Contact our
customer services.
Sparkokay.
Carburettor
set upwrong.
Starter handle
pulled too slowly.
Pull starter handle
more sharply.
Wrong type of fuelused. Check.
Overloading. Check theratedpower.
Specifications
Model IG2400S
Generator
Output voltage 230 VAC
Rated power 1.8kW
Max power 2.0kW
DC output 12 V DC, max 8.3A
Engine
Model 160F
Type 1-cylinder, 4-stroke, OHC air-cooled petrol engine
Displacement 113cc
Engine oil SAE 10W-30
Oil capacity 0.5 litres
Spark plug NGK CR7HSA (0.6–0.7 mm gap)
Other
Fuel Petrol min. 90RON.
Fuel tank capacity 4.5l
Sound power (LwA) 90 dB(A)
Starting system Magnapull
Dimensions 510×302×410 (L×W×H )
Weight 22kg
Operating time approx. 5hours
