Cotek S600 Series - Electrical Performance

2-2. Electrical Performance
Specification
Model No.
Item S600-112 S600-124 S600-148 S600-212 S600-224 S600-248
Continuous Output Power 600W
Maximum Output Power (3Min.) 680W
Surge Rating 800W
Input voltage 12V 24V 48V 12V 24V 48V
Output Voltage
100 / 110 / 120V +/- 3% 220 / 230 / 240V +/- 3%
Frequency
(Switch Selections)
50 / 60Hz +/- 0.05%
Efficiency (full load) 87.0% 90.0% 92.0% 90.0% 93.0% 94.0%
No Load Current Draw 0.87A 0.43A 0.23A 0.83A 0.43A 0.22A
Output Waveform Pure Sine Wave ( THD < 3% )
Output voltage Regulation 100 / 110 / 120V RMS -10%/+4% 220 / 230 / 240V RMS -10%/+4%
Input Voltage Regulation
10.5-15
VDC
21.0-30
VDC
42-60
VDC
10.5-15
VDC
21.0-30
VDC
42-60
VDC
Input Level Indicator
Load Level Indicator
Red / Orange / Green LED
Failure Indicator Red LED
Protection
Overload, Short Circuit, Reverse Polarity (Fuse),
Over / Under Input Voltage, Over Temperature.
Safety Certification UL458 EN60950-1
EMC FCC Class B
EN50081-1: 1992
EN50082-1: 1992
EN55022B: 1994
EN61000-4-2: 1995
EN61000-4-3: 1996
ENV50204: 1995
e-mark
e13-020866
Operating Temperature Range
0 - 33 ℃ 0 - 40 ℃
Storage Temperature Range
-30℃ to 70℃
Cooling Loading controlled cooling fan
Dimensions 295(L) x 180(w) x 72(H) mm / 11.61(L) x 7.09(W) x 2.83(H) Inch
Weight 2.7 kgs. / 5.4 Lbs.
Note: The specifications are subject to change without notice.
3
