Operator’s Manual
20969 CRT Tiller
ILLUSTRATED PARTS BREAKDOWN MOTOR MOUNT
ITEM # PART # DESCRIPTION QT Y.
1 13826 BOLT M8 X 1.25 X 25 HHCS
GR8.8 ZN FT
1
2 W1200114 WASHER M8 X 1.9 SPRLK
BLK OX HIGH COLLAR
7
3 20143 WASHER M8 X 16 X 1.6 FLAT
ZN
12
4 13453 ASSEMBLY BELT GUARD
WITH TAB
1
5 W1200115 BOLT M6 X 1 X 12 HHCS
GR8.8 ZN FT
1
6 1407 SPRING FORWARD ARM 1
7 4711 BOLT M8 X 1.25 X 12MM
HHF YZN
2
8 20144 BOLT M8 X 1.25 X 60 HHCS
GR 8.8 ZN FT
4
9 31315 BELT DRIVE 26IN 4LXA
POWER RATED
1
10 20798 PULLEY SINGLE GROOVE
ENGINE 19.060 MM ID
1
11
W1265V0904
BOLT M8 X 1.25 X 20 HHCS
ZN GR8.8
2
12 19869 WELDMENT CABLE PULL
PLATE NP
1
13 20141 WASHER M6 X 12 X 1.6 FLAT
ZN
4
14 3364 KEY SQUARE 3/16 X 5/8 1
15 19945 BOLT M8 X 1.25 X 20 HHFCS
GR8.8 ZN
4
16 53618 CLIP BELT GUARD TILLER
DEC 2005
2
17 18098 BOLT M8 X 1.25 X 45 HH GR
8.8 ZN
4
18 31306BLK TAB BELT GUARD SUPPORT
COMPACT RT BLACK
1
19
W1265V0900
NUT M8 X 1.25 HNYLK GR8.8
ZN
10
20 11946 BOLT M6 X 1.0 X 45 HHCS
GR8.8 ZN
1
21 20148 WASHER M6 X 18 X 1.6 FLAT
ZN
3
ITEM # PART # DESCRIPTION QT Y.
22 19895 GUIDE BELT WIRE FORM
REAR TINE NP
1
23
W1265V0913
NUT M6 X 1.0 HNYLK GR8.8
ZN
5
24 18103 BOLT M6 X 1.0 X 40 HH GR
8.8 ZN
4
25 20524 PAN LOWER COUNTYLINE
NP
1
26 20521 PLATE TRANNY COVER
HOOD MOUNT CL NP
1
27 53413 DIPSTICK REAR TINE
TRANSMISSION
1
28 19905 WASHER M10 X 20MM X
2MM FLAT ZN
1
29 20145 BOLT M10 X 1.5 X 50 HHCS
GR 8.8 ZN PT
1
30 53596B YOKE ZINC PLATED CLEVIS 1
31 53617 ARM FORWARD REAR TINE 1
32 1416 PIN CLEVIS 6.3 X 16.8 MM 1
33 13364 PULLEY IDLER FORWARD
10MM ID
1
34
W1265V0903
NUT M10 X 1.5 HNYLK GR
8.8 ZN
1
35 53637 BUSHING 8.3 MM X 12.4 MM
6.7 MM THK
1
36 739 BELT GUIDE REVERSE 1
37 1418 PIN COTTER 5/64 X 1/2
EXTENDED PRONG ZN
1
38* 20902 ENGINE 2000 SERIES 196CC
KOHLER HORZ
1
39 20110 VENT BREATHER M10 X 1.5 1
40 20919 SET SCREW M6 X 1.0 X 8
SCPC BLK OXIDED
2
41 20407 ORING 14MM ID X 1.8MM
ROUND
1
42 3245 WASHER M8 8.4MM X 24MM
X 2.2MM ZN
2
* See engine manual for additional information
