Operator’s Manual
20969 CRT Tiller
ILLUSTRATED PARTS BREAKDOWN - Transmission, Tines, & Hood
ITEM# PART # DESCRIPTION QT Y.
1 20150 BOLT M8 X 1.25 X 15 HHCS
GR8.8 ZN
4
2 W1200114 WASHER M8 X 1.9 SPRLK BLK
OX HIGH COLLAR
11
3 W1200115 BOLT M6 X 1 X 12 HHCS GR8.8
ZN FT
6
4 20003 WELDMENT TAIL MOUNT REAR
TINE NP
1
5 18039 PIN LOCK 8MM X 40MM PIPE
SAFETY PIN
1
6 11509 BOLT M101.5 X 45 MM HHFCS
GR8.8 ZN
2
7 1900LCRT TINE SET ASSEMBLY LSCRT
RSSRT
1
8 1900RCRT TINE SET ASSEMBLY RS CRT LS
SRT
1
9 W1200119 WASHER M10 X 2 THK SPRLK ZN
HIGH COLLAR
2
10 W1265V0903 NUT M10 X 1.5 HNYLK GR 8.8
ZN
2
11 21018 TIRE WHEEL ASSEMBLY WHITE
10 LUG 12 DEEP
2
12 13601 KNOB M8 BLACK THREE STAR 1
13 53655 WELDMENT DRAG STAKE CRT
TILLER DEC 2005
1
14 20109 LOCK PIN 7 MM X 44 MM 2
15 20138 SNAP RING 25MM EXTERNAL 2
16 20108 PULLEY TRANNY SINGLE
GROOVE 127MM 4L
1
17 3245 WASHER M8 8.4MM X 24MM X
2.2MM ZN
1
18 W1265V0904 BOLT M8 X 1.25 X 20 HHCS ZN
GR8.8
1
19 20111 TRANSMISSION CRT SHORT 1
20 20892 WELDMENT HOOD WITH
EXTENSION HOLES CL NP
1
21 20891 WELDMENT SIDE SHIELD
COUNTYLINE NP
2
22 W1265V0913 NUT M6 X 1.0 HNYLK GR8.8 ZN 6
23 20141 WASHER M6 X 12 X 1.6 FLAT ZN 12
24 20197 KEY SQUARE 6MM X 20MM 1
25 19864 GASKET TILLER TRANSMISSION
COVER NP
2
26 W1265V0900 NUT M8 X 1.25 HNYLK GR8.8 ZN 2
27 19945 BOLT M8 X 1.25 X 20 HHFCS
GR8.8 ZN
7
