Repair Parts 9
1
2
2
3
4
4A
4B
4C
5
7
6
9
8
5676 0807
IN
OUT
Ref. Description Qty. Part Number
1 Pump Body 1 *
2 3/4” NPT x 3/4” Garden Hose Adapter 2
3 Fill Plug 1 **
4 Overhaul Kit (Includes 4A, 4B, 4C) 1 FPPKG 225-P2
4A Impeller 1 ***
4B Shaft Seal 1 ***
4C Square Cut O-Ring 1 ***
5 Seal Plate 1 ***
6 Handle With Hardware 1 C54-30
7 Power Cord 1 PS17-1507
8
Brush Kit (Includes 1 Pair of Brushes
with springs and Retainer Caps)
1 FPPKG 226-P2
9 Motor 1 *
* If Pump Body or Motor fail, replace entire pump.
** NOTICEFillPlugthreadsdonotmatchinletordischargethreads;FillPlug
is not interchangeable with Garden Hose Adapter (Key No. 2).
*** Not available separately.
† Purchase locally.
