Coverstar Eclipse - System Diagram

11
Installation Check & Trouble Shooting System Diagram
Cover Leading Edge
Slider
Cover Guide
Non-Motor End Support Bracket
Motor Side Return Pulley
Torque Limiter Brake
Adjustment Bolts
Electric Motor
Non-motor Side Reel Pulley
Gear Assembly
Electrical Junction Box
Motor Side Reel Pulley
Non-motor Side Pulley
Brake Pad
Adjustment Jam Nut
Take-up Tube Brake
