INDICATORS AND CONTROLS
Indication part/Operation part
Indicators Controls
Coldwater
temperature
indicator
Power indicator
Ifyouconnectthepower,
theindicatoristurnedon.
UV cycle indicator
Incasethatstoragetankisfull
forahour,“UV”lamplightson
and lamplightsoinserial.
incasethat“UV”lampblinks,
changetheUVlamp.
Power
indicator
1
UVcycle
indicator
2
Waterlevel
indicator
3
Hotwater
temperature
indicator
6
Hotwater
temperature
levelindicator
8
Coldwater
temperature
levelindicator
9
7
Hotwater
mode
indicator
4
Coldwater
mode
indicator
5
Hotwatermode
selectionbutton
1
Coldwatermode
selectionbutton
2
1
Water level indicator
Theindicatoristurnedon
accordingtothewaterlevel
inthestoragetank.Basically,
oneblankisturnedon.
3
Cold water mode
indicator
Whenyouselectcoldwater
mode,theindicatoris
turnedon.
5
Hot water temperature
indicator
Theindicatoristurnedon
accordingtothehotwater
temperature.ThemoreLEDs
areon,thehigherthehotwater
temperatureis.
6
Hot water mode
indicator
Whenyouselecthotwater
mode,theindicatoris
turnedon.
