Coway P-220L - Disassembling And Reassembling The Product; Disassembling The Top-Cover Assembly

Disassembling and refitting
4-2
Coway co., Ltd
4-2 Disassembling and reassembling the product
4-2-1 Disassembling the Top-Cover Assembly
No. Part names Description Reference picture
1 Water-
V
essel
Assembly
1)
Separate the Water-Vessel
Assembly by pulling it in the
direction of the arrow in the
figure.
2 Top-Cover
Assembly
1)
Separate the Top-Cover
Assembly by pulling it in the
direction of the arrow in the
figure.
2) Separate the clip of the Main
Tank-Cap Assembly.
