Coway P-220L User Manual

Circuit diagrams
8-2
Coway co., Ltd
8-2 SMPS PBA
This document is Coway’s technical property. Only the person approved by the company may use this document.
24VDC/1.4A
NEUTRALLIVE
4 6
YW369-03V
5
31
FG
1400242
1
CN201
4
CN101
2
GND
2
GND 5VDC 0.4A
C203
470uF/10V
D102 PR1007
!
!
L201 4.7uH
R104 10 1/4W J
R210
36K 1/8W F
!
D202 MBR10H200CT
R208 27K 1/8W F
D201 100V 5A
C207 0.1uF/100V
C206 470uF/35V
R203
1.5K 1W
!
C208
0.01uF/100V
LTV817B PC101-A
C209
N.A
R103 47K 2W MINI J
ZD101
1N5252B 24V
U201
KA7805AE
1 3
2
IN OUT
GND
TH101 5D-13
!
!
VX101
14D751
LF101
CV613400SH
R101
1.2M 1/2W J
D101 UF4007
C104 100uF/35V
-
+
D2SB60 1.5A 600V
BD101
R209 3.3K 1/8W F
U202 FAN431
!
C106
100pF/1KV
!
CY103
4700pF/250VAC-Y1
R207 1K 1/8W F
C102 102/400V
PC101-B LTV817
T101
!
!
!
R205 300 1/8W J
C204 1000uF/35V
C210 100uF/25V
C101
100uF/450V
F101 T3.15AL/ 250V
R102
75K 1/2W J
C105
0.1uF/100V
FSDM0465R
U101
4 6 1
5
2 3
VFD
VSTR DRAIN
N.A GND
VCC
C209 102/1KV
CX101
0.47uF-M/275VAC
C103
0.047uF/100V
R211
4.7K 1/8W J(N/A)
ZD102
1N5252B 24V
