Parts List
SPECIFICATIONS
# Part Number Description Qty
1 09001019 Mounting Rail Subassy 2
2 09002120 Left Frame 1
3 09002121 Right Frame 1
4 09002122 Accessory Shelf 1
5 09001023 Hub Half Subassy 2
6 09002123 Right/Left Plate 2
7 09002127 Long Axle 1
8 09002128 Short Axle 1
9 90072635 Outlet Fitting 1
10 09003004 Outlet Seal, Water System 1
11 90022204 Screw, M4 × 12, Pan, Cross 12
12 90022605 Set Screw, M6 × 12 1
13 90022301 Screw, M6 × 30, Allen 1
14 90052026 O-Ring, 19 × 2.65 4
15 09003001 Swivel Cover 2
16 09003002 Right Plastic Bearing 2
17 09002104 Sleeve 1
18 90032300 Retainer Clip, 25 mm 1
19 09001005 Support Tube Subassy 1
# Part Number Description Qty
20 90022601 Screw, M6 × 20, Hex Flange 2
21 90072637 Inlet Brass Screw 1
22 90072636 Inlet Brass Nut 1
23 09003003 Seal Washer 3
24 09001021 Crank Handle Subassy 1
25 09001013 Leader Hose Subassy 1
26 90022202 Screw, M4 × 8, Pan, Cross 6
27 90102504 Locating Pin 2
28 90022504
Screw, M5 × 15, Oval
Recess, Cross
1
29 90022031 Screw, Wood, St 4.8 × 38 8
30 95024074 Plastic Anchor 8
31 95024046 Masonry Anchor, 10 × 60 8
32 09001022 Mounting Clip Subassy 4
33 95024050 Screw, Lag, St 9.5 × 64, Hex 8
