100361
TABLE OF CONTENTS
Introduction ............................ 4
Before You Begin ...................... 4
Manual Conventions ....................... 5
Safety rules ............................ 5
Parts ................................ 6
Parts Included ........................ 6
Hardware Included ..................... 6
Recommended Tools (not included) .......... 7
Replacement Parts ..................... 7
Assembly .............................. 8
Install Mounting Rail to Masonry Wall ........ 8
Install Mounting Rail to a Stud Wall .......... 9
Install Mounting Clips ................... 9
Crank Assembly ...................... 10
Attach the Leader Hose ................. 10
Moving or Storing the Hose Reel ........... 10
Specifications .......................... 12
Parts Diagram ........................ 12
Parts List ........................... 13
DETACHABLE
HOSE REEL
