CPI MOTOR
CRANKSHAFT/CRANKCASE GTR50
《8-3》
CRANKCASE INSTALLATION
Install the crankshaft bearing into the left crankcase.
Install the crankshaft bearing into the right crankcase.
Install the crankshaft into the left crankcase.
Install the oil seal into the left crankcase.
