4
LEDS
POWER The Cradlepoint AER1600/AER1650 must be powered using an approved 12V
DC power source.
• Green = Powered ON.
• No Light = Not receiving power. Check the power switch and the power source
connection.
• Flashing Amber = Attention. Open the administration pages (see page 7) and
check the router status.
ETHERNET WAN Indicates information about a data source connected to the
Ethernet WAN port.
• Blue = Connected to an active Ethernet WAN interface.
WiFi BROADCAST (only on AER1600) These two LEDs indicate activity on the WiFi
broadcast for both the 2.4 GHz and 5 GHz bands.
• 2.4GHz (green) = 2.4 GHz WiFi is on and operating normally.
• 5GHz (blue) = 5 GHz WiFi is on and operating normally.
WAN
VPN Indicates information about a VPN data source.
• Green = Active VPN tunnel.
VPN
