1. Unpacking Your Fan.
Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor housing
and place on carpet or Styrofoam to avoid
damage to nish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.
2. Parts Inventory.
a. canopy. 1 piece
b. hanging bracket. 1 piece
c. downrod and hanging ball. 1 piece
d. motor housing. 1 piece
e. yoke cover. 1 piece
f. weatherproof hanging ball cover.
(in hardware pack). 1 piece
g. blade arm. 5 pieces
h blade. 5 pieces
i. hardware packs
*Drawings in this manual are representative only
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
a
b
c
d
g
i
h
page 3
f
e
