PARTS
K
EY PART
N
O. NO. DESCRIPTION QTY.
1 OR90055 M6x80mm CARRIAGE HD SCREW 1
2 OR90152 EYESHIELD 1
3
OR90059 M6mm FLAT WASHER 1
4
OR90001 M6mm KNOB 1
5
OR90002 SPACER 1
6 OR90488 SPARK ARRESTOR-L.H 1
7
OR90059 M6mm FLAT WASHER 1
8
OR90333 M6x12mm HEX HD SCREW 1
9
OR90001 M6mm KNOB 1
10 OR90059 M6mm FLAT WASHER 1
11 OR90152 EYESHIELD 1
12 OR90055 M6x80mm CARRIAGE HD SCREW 1
13 OR90002 SPACER 1
14 OR90489 SPARK ARRESTOR-R.H 1
15 OR90333 M6x12mm HEX HD SCREW 1
16 OR90059 M6mm FLAT WASHER 1
17 OR90567 PAN HD SCREW M6x60mm 3
18 OR90059 M6mm FLAT WASHER 3
19 OR94740 OUTER WHEEL GUARD-RH 1
20 OR90499 HEX NUT M16 1
21 OR71446 WHEEL FLANGE 1
22 OR71447 GRINDING WHEEL, 120 GRIT-
10" DIA x 1" WIDE x 1-1/4" BORE 1
23 OR71448 WHEEL BUSHING 1
24 OR71446 WHEEL FLANGE 1
25 OR90501 PAN HD SCREW M6x16mm 4
26 OR90502 M6mm LOCK WASHER 4
27 OR94741 INNER WHEEL GUARD ASSEMBLY-RIGHT, INCL:
REF 28 1
28
OR90526
ROTA
TION LABEL 1
29 OR90059
M6mm FLA
T
W
ASHER 3
30 OR90235 HEX NUT
M6
3
31
OR90502 M6mm LOCK WASHER 3
33
OR94742
MOT
OR ASSEMBLY
, INCL: REF 34 & REF 36
1
34 OR94743 NAME PLA
TE LABEL
1
36
OR94744 SPEC LABEL 1
38
OR90502
M6mm LOCK W
ASHER
3
39
OR90235
HEX NUT
M6
3
40
OR90059
M6mm FLA
T
W
ASHER
3
41
OR94745
INNER WHEEL
GUARD
ASSEMBL
Y
-LEFT
, INCL:
REF 42 1
42 OR90526 ROTATION LABEL 1
43 OR90502 M6mm LOCK WASHER 4
44 OR91826 PAN HD SCREW M6x16mm 4
45 OR71446 WHEEL FLANGE 1
46 OR90520 GRINDING WHEEL, 60 GRIT-
10" DIA
x 1" WIDE x 1-1/4" BORE 1
47 OR71448 WHEEL BUSHING 1
48 OR71446 WHEEL FLANGE 1
49 OR90500 HEX NUT M16-LEFT HAND 1
50 OR94746 OUTER WHEEL GUARD-LH 1
51 OR90059 M6mm FLAT WASHER 3
52 OR90567 PAN HD SCREW M6x60mm 3
53 OR94747 LEFT TOOL REST ASSY, CONST OF:
REF 54 TO REF 56E 1
5
4 OR90203 LEFT TOOL REST SUPPORT 1
5
5 OR90204 LEFT TOOL REST 1
5
6A OR90625 5/16 FLAT WASHER 1
56B OR90155 KNOB 5/16 - 18 1
56C OR90311 M8 FLAT WASHER 2
56D OR90248 M8 LOCK WASHER 2
5
6E OR93917 M8 x 20mm HEX HEAD SCREW 2
5
7 OR94748 RIGHT TOOL REST ASSY, CONST OF :
R
EF 58 TO
REF 60E 1
58 OR90191 RIGHT TOOL REST SUPPORT 1
59 OR90192 RIGHT TOOL REST 1
60A OR90155 KNOB 5/16 - 18 1
60B OR90625 5/16 FLAT WASHER 1
60C OR93917 M8 x 20mm HEX HEAD SCREW 2
60D OR90248 M8 LOCK WASHER 2
60E OR90311 M8 FLAT WASHER 2
63 OR71428 LIGHT ASSY, INCL: 1
64 OR90544 LIGHT WARNING LABEL 1
66 OR90227 M10mm LOCK WASHER 1
67 OR90228 M10x1mm HEX NUT 1
68 OR90507 PAN HD SCREW M5x8mm 2
69 OR90362 M5 EXT TOOTH WASHER 2
70 OR71429 CORD CLAMP 1
71 OR71430 CLAMP PLATE 1
72 OR94749 BASE 1
73 OR71454
POWER CORD
1
74 OR90248 M8mm LOCK WASHER
2
75
OR90504
HEX HD SCREW M8x18mm 2
76 OR71455
CLAMP
1
77 OR71456 CAP
ACIT
OR(100
°
F) 1
78
OR71450 END CAP 2
79
OR90362
M5 EXT
T
OOTH WASHER
1
80 OR90507 P
AN HD SCREW M5x6mm
1
82
OR90362 M5 EXT T
OOTH W
ASHER
2
83
OR90863
P
AN HD SCREW M5x12mm
4
84
OR71436
P
AD
4
85
OR71437
BASE PLA
TE
1
86
OR90333
M6x10mm HEX HD SCREW
2
87
OR71438
W
A
TER
TRA
Y
1
88
OR90505
P
AN HD SCREW M5x12mm
2
89
OR90362
M5 EXT
T
OOTH W
ASHER
4
90
OR71439
SWITCH
1
91
OR71424
SWITCH PLA
TE
1
92
OR90362
M5 EXT
T
OOTH W
ASHER
2
93
OR90507
P
AN HD SCREW M5x8mm
2
94
OR71440
DIAMOND WHEEL
DRESSER
1
95
OR90507
P
AN HD SCREW M5x8mm
2
96
OR90050
10mm x 12mm OPEN END WRENCH (NOT
SHOWN)
1
97
OR90510
BEARING (NOT
SHOWN)
2
98
OR94750
OWNERS MANUAL
(NOT
SHOWN)
1
10-IN. PROFESSIONAL BENCH GRINDER PARTS LIST MODEL NO. 152.220600
When servicing, use only CRAFTSMAN replacement parts. Use of any other parts may create a HAZARD or cause
product damage.
Any attempt to repair or replace electrical parts on this Bench Grinder may create a
HAZARD unless repair is done
by a qualified service technician. Repair service is available at your nearest Sears Service Center.
Always order by PART NUMBER, not by key number.
WARNING
!
WARNING
!
K
EY PART
N
O. NO. DESCRIPTION QTY.
