To Next PageTo Next PageHow to fix a Craftsman Saw when the motor does not start?
If your Craftsman Saw motor does not start, make sure the switch is fully pressed in (1/2 inch) or in the “ON” position. If that's not the issue, the switch, capacitor, or motor itself might be defective and need replacement. Also, check for low line voltage and correct it by plugging the saw directly into the wall outlet if you're using an extension cord.
Why does the motor stall or the circuit breakers open frequently on my Craftsman 152.221240?
If the motor of your Craftsman Saw stalls, thermal-overload trips, or circuit breakers open frequently, it could be due to several reasons. First, there might be a circuit overload, so try reducing the load by turning off other appliances. Second, check for low line voltage and correct it by plugging the saw directly into a wall outlet instead of using an extension cord. Third, the motor might be overloaded, so reduce the load on the motor by slowing down the feed rate of the workpiece. Fourth, ensure that correct fuses are installed on circuit breakers by a qualified electrician. Finally, inspect the motor for short circuits, loose connections, or worn insulation on lead wires and have them replaced; also, check all power lead connections.
Why is the motor on my Craftsman 152.221240 Saw running too hot?
If the motor of your Craftsman Saw is running too hot, it could be due to restricted air circulation caused by dust accumulation. Clean the dust to restore normal air circulation around the motor. Another possible cause is motor overload, so reduce the load on the motor.
What to do if my Craftsman Saw motor starts slowly?
If your Craftsman Saw motor starts slowly or fails to reach full speed, there are a few potential causes. Begin by checking for low line voltage and correct it; use a multi-meter and avoid extension cords by plugging directly into the wall outlet. If voltage isn't the issue, the motor windings or capacitor might be defective and require replacement.
Why does my Craftsman 152.221240 Saw vibrate excessively?
If your Craftsman Saw vibrates excessively, the issue might stem from several sources. The blade could be warped, in which case you should replace it. A damaged drive belt could also be the culprit, so consider replacing that as well. Ensure the work surface is even; reposition the saw on a flat surface and adjust the leveling feet if available. Lastly, check that the saw is securely mounted and tighten all hardware.
Why are the handwheels on my Craftsman Saw hard to turn?
If the handwheels on your Craftsman Saw are hard to turn, first ensure that the Handwheel Lock Knob has been loosened. If the problem persists, dust accumulation on the tilting or beveling gears inside the cabinet might be the cause. In this case, clean off the tilt and bevel gear assemblies.
What to do if the workpiece binds when ripping with my Craftsman Saw?
If the workpiece binds, burns, or stalls the motor when ripping with your Craftsman Saw, it could be due to a dull blade, so try sharpening or replacing it. Another cause might be a warped or twisted board, which should be replaced. Also, ensure the rip fence is parallel to the blade.
Why doesn't the miter gauge move smoothly on my Craftsman 152.221240 Saw?
If the miter gauge on your Craftsman Saw does not move smoothly, the miter gauge groove and bar might be dirty, so clean them. Alternatively, the set-screws in the miter gauge bar could be out of adjustment; adjust them accordingly.
Why doesn't my Craftsman 152.221240 Saw blade cut true at 90 or 45 degrees?
If your Craftsman Saw blade does not cut true at 90 or 45 degrees, it could be due to a dull blade, so sharpen or replace it. Alternatively, the indicator arrow may not be properly adjusted, so adjust the bevel indicator arrow. Also, check if the positive stops are not set properly and adjust the 90 and 45-degree positive stops.
Essential safety rules for operating the table saw.
Steps before starting, including grounding, environment, and PPE.
Recommended gauge and condition for extension cords.
Procedures for safe electrical grounding to prevent shock.
Warnings on hazardous substances, key operating rules, and detailed precautions.
List of recommended accessories for the table saw.
Instructions for making a featherboard and a pushstick for safety.
Procedures for unpacking, cleaning, and verifying all parts.
Labeled diagram identifying all major parts of the table saw.
Installing leveling feet, dust port, belt, extension wings, and handwheels.
Installing blade guard, splitter, hooks, fence rails, extension table, guide tube, switch, knobs, and outfeed table.
How to connect the switch cord to the motor for power control.
Steps to assemble the miter gauge body, clamp, and depth stop.
Steps for permanently securing the table saw to the floor.
Managing switch lock, overload, adjusting blade height and tilt.
Setting bevel stops, adjusting arrow, and checking/correcting blade alignment.
Operating fence, adjusting cursor, alignment, and lock handle.
Lubrication, table insert leveling, voltage change, and blade replacement procedures.
Using miter gauge for crosscuts and rip fence for ripping operations.
Instructions for using dado blades and molding head cutters.
Adjusting mechanisms for play and protecting cast iron table from rust.
Table saw lubrication and cleaning steps.
Guide to identify and resolve common issues with the table saw.
Comprehensive list of all replacement parts with part numbers.
Information on in-home and carry-in repair services from Sears.
