OPERATION
14
HOW TO DISCONNECT THE TRANSMISSION
To push the unit, use the automatic drive disconnect to release
the transmission. (Figure 9)
1. The engine must be off.
2. The automatic drive disconnect is located under the left side
of the seat deck next to the hydrostatic transaxle.
3. To release the transmission and push the unit, pull and twist the
automatic drive disconnect.. Latch the automatic drive dis-
connect in the PUSH position (Figure 9). The transmission is
now released and the unit can be pushed.
NOTE: In cold weather, the heavy viscosity oil in the
transmission will make the unit difficult to push.
4. To engage the transmission, unlatch the automatic drive dis-
connect. The transmission is now connected and ready to op-
erate.
Figure 9
Automatic Drive Disconnect
DRIVE POSITION
Automatic Drive Disconnect
PUSH POSITION
400150
