Craftsman 536.270321 - Page 59

REPAIR PARTSBRIGGS & STRATTON ENGINE
59
MODEL 21B807-0326-E1
51∅DKz692137 Gasket−Intake
94 695425 Kit−Idle Mixture
95 D690718 Screw
(Throttle Valve)
98 695408 Kit−Idle Speed
104 D694918 Pin−Float Hinge
105 D696136 Valve−Float Needle
108 697723 Valve−Choke
117 699897 Jet−Main
(Standard)
118 699898 Jet−Main
(High Altitude)
121 698787 Kit−Carburetor Overhaul
125 699916 Carburetor
127 D690727 Plug−Welch
130 698774 Valve−Throttle
131 698776 Kit−Throttle Shaft
133 694914 Float−Carburetor
135 698780 Tube−Fuel Transfer
137 D
z698781 Gasket−Float Bowl
141 698778 Kit−Choke Shaft
187 791805 Line−Fuel
(Formed)
188 691693 Screw
(Control Bracket)
202 691841 Link−Mechanical
Governor
209 792602 Spring−Governor
216 691840 Link−Choke
222 694042 Bracket−Control
227 691374 Lever−Governor Control
232 691842 Spring−Governor Link
240 394358s Filter−Fuel
265 691024 Clamp−Casing
267 695134 Screw
(Casing Clamp)
276 D
z695410 Washer−Sealing
404 691691 Washer
(Governor Crank)
505 691251 Nut
(Governor Control Lever)
521 690581 Shield−Cable
562 691119 Bolt
(Governor Control Lever)
601 791850 Clamp−Hose
614 691620 Pin−Cotter
616 692012 Crank−Governor
617 D692138 Seal−O Ring
(Intake Manifold)
634 KD698779 Spring/Seal Assembly
(Choke Shaft)
947 699915 Solenoid−Fuel
975 699502 Bowl−Float
977 790032 Gasket Set−Carburetor
987 D698777 Seal−Throttle Shaft
1091 691333 Cap−Limiter
1127 695407 Screw
(Float Bowl)
1266 KD691917 Seal−O Ring
(Intake Elbow)
1266A KD697123 Seal−O Ring
(Intake Elbow)
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
400150
