Generator
Customer Helpline
1-800-222-3136
120/240 Volt
Electric Start
10,000 Watt
AC GENERATOR
Sears, Roebuck and Co., Hoffman Estates, IL 60179
Owner’s Manual
Model No. 580.328300
CAUTION:
Before using this product, read this
manual and follow all its Safety Rules
and Operating Instructions.
Part No. B4419 Draft 1 (6/14/2000) Printed in the U.S.A.
Visit our Craftsman website: www.sears.com/craftsman
• Safety
• Assembly
• Operation
• Maintenance
• Parts
• Español
HOURS: Mon. - Fri. 8 a.m. to 5 p.m. (CT)

Table of Contents

Questions and Answers

  • C
    Courtney MillerAug 4, 2025
    What to do if my Craftsman 580.328300 Portable Generator engine shuts down during operation?
    • D
      Dylan HernandezAug 4, 2025
      If your Craftsman Portable Generator engine shuts down during operation, the possible causes are: * The unit is out of gasoline, in which case you should fill the fuel tank. * The oil level is low, in which case you should fill the crankcase to the proper level. * There is a fault in the engine, in which case you should contact a Sears service facility.
  • A
    Adam AlexanderAug 9, 2025
    How to fix a Craftsman Portable Generator that runs but has no AC output?
    • K
      Kristy ButlerAug 9, 2025
      If your Craftsman Portable Generator is running, but there's no AC output, there are several potential causes. First, check the circuit breaker and reset it if it's open. Inspect the cord set for poor connections or defects and repair as necessary. Ensure the connected device is functioning correctly by testing with another device in good condition. If none of these steps resolve the issue, there may be a fault in the generator, and you should contact a Sears service facility.
  • B
    betty95Aug 14, 2025
    What to do if my Craftsman 580.328300 Portable Generator bogs down when a load is connected?
    • K
      Kayla CummingsAug 14, 2025
      If the engine of your Craftsman Portable Generator runs well but bogs down when loads are connected, it could be due to several reasons. A short circuit in a connected load could be the cause, so disconnect the shorted electrical load. The generator might be overloaded, so refer to the “Don’t Overload the Generator”. If the engine speed is too slow or there's a shorted generator circuit, contact a Sears service facility.
  • M
    matthewhuberAug 19, 2025
    Why does my Craftsman 580.328300 Portable Generator engine lack power?
    • B
      Brenda ClaytonAug 19, 2025
      If your Craftsman Portable Generator engine lacks power, it may be due to a few reasons. The load might be too high, so check “Don’t Overload the Generator”. Also, a dirty air filter can cause this issue, so replace the air filter. If neither of these solutions works, the engine may need to be serviced, and you should contact a Sears service facility.
  • R
    Robert LopezAug 25, 2025
    What causes a Craftsman 580.328300 Portable Generator engine to hunt or falter?
    • M
      mcaseAug 25, 2025
      If your Craftsman Portable Generator engine “hunts” or falters, it could be because the choke is opened too soon; in this case, move the choke to the halfway position until the engine runs smoothly. Alternatively, the carburetor might be running too rich or too lean, and you should contact a Sears service facility.
  • M
    Matthew SmithOct 29, 2025
    Why won't my Craftsman Portable Generator start or why does it run rough?
    • N
      Nicole MitchellOct 29, 2025
      If your Craftsman Portable Generator engine won't start or runs rough, several factors could be at play. First, ensure the fuel tank is filled with gasoline. If the gasoline is stale, drain the tank and fill it with fresh fuel. Check that the spark plug wire is securely connected to the spark plug and that the spark plug is in good condition; replace it if necessary. Also, verify that the air cleaner is not dirty; clean or replace it if needed. Make sure that there is no water in the gasoline, drain the tank and fill it with fresh fuel if needed. Check the oil level and fill the crankcase to the proper level if it's low. If the engine is overchoking, put the choke lever to the “no choke” position. For excessively rich fuel mixture, intake valve issues, or loss of compression, contact a Sea...

Summary

WARRANTY

Limited Warranty for Portable Generators

Details warranty terms for consumer and commercial use, including covered parts and periods.

SAFETY RULES

General Safety Precautions

Lists critical safety rules and warnings for operating the generator.

ASSEMBLY

Battery Connection

Wheel Kit Installation

Step-by-step guide for installing the wheel kit onto the generator.

OPERATION

Know Your Generator

Before Starting the Generator

Pre-operation checks and procedures, including adding oil and gasoline.

HOW TO USE YOUR GENERATOR

Grounding the Generator

Explains the importance and method of grounding the generator.

Connecting Electrical Loads

Guidelines for safely connecting electrical devices to the generator.

Starting the Engine

Step-by-step instructions for starting the generator's engine.

Stopping the Engine

Procedures for safely shutting down the generator's engine.

Engine Troubleshooting

Steps to diagnose and resolve common engine starting issues.

MAINTENANCE

Maintenance Schedule

Outlines recommended maintenance tasks and intervals.

PRODUCT SPECIFICATIONS

Engine Specifications

Generator Specifications

Engine Maintenance

Checking Oil Level

Details how to check the engine oil level before operation.

Changing the Oil and Oil Filter

Steps for performing an oil and filter change on the engine.

Inspecting the Spark Plugs

Procedure for inspecting, cleaning, and gapping spark plugs.

Service Air Cleaner

Engine Governed Speed

Carburetor Adjustments

TROUBLESHOOTING

Troubleshooting Guide

A table listing common problems, their causes, and solutions.
