7
100F 0.1F
(5% reading + 5 digits)
Frequency 5.999Hz 0.001Hz
(1.5% reading + 1 digits)
59.99Hz 0.01Hz
599.9Hz 0.1Hz
(1.2% reading + 3 digits)
5.999kHz 0.001kHz
59.99kHz 0.01kHz
599.9kHz 0.1kHz
5.999MHz 0.001MHz
(1.5% reading + 4 digits)
9.999MHz 0.001MHz
Sensitivity: 0.5V rms <500kHz; 3V rms >500kHz
Duty Cycle
0.1 to
99.9%
0.1%
(1.2% reading + 2 digits)
Pulse width: 100µs to 100ms, Frequency: 5Hz
to 150kHz
NOTE: Accuracy is stated at 65
o
F to 83
o
F (18
o
C to 28
o
C) and
less than 75% RH.
Note: Accuracy specifications consist of two elements:
(% reading) – This is the accuracy of the measure circuit.
(+ digits) – This is the accuracy of the A/D converter.
Enclosure Double molded, waterproof (IP67)
Shock (Drop Test) 6.5 feet (2 meters)
Diode Test Test current of 0.3mA typical, open
circuit voltage 1.5V DC typical
Continuity Check Audible signal will sound if the
resistance is less than 100
(approx.), test current <0.3mA
Input Impedance 7.8MΩ
AC Response Average responding
ACV Bandwidth 50Hz to 400Hz
Crest Factor ≤3 at full scale up to 500V,
decreasing linearly to ≤1.5 at
1000V
Display 4,000 count backlit liquid crystal
Overrange indication “OL” is displayed
Auto Power Off 30 minutes (approximately)
