7
SPECIFICATIONS
Function Range Resolution Accuracy
2nF 1pF
20nF 10pF
200nF 0.1nF
2µF 1nF
Capacitance
20µF
10nF
±(4.0% reading + 3 digits)
20kHz 10Hz
±(1.5% reading + 10 digits)
Frequency
Sensitivity: 200mVac RMS to 10Vac RMS
0 to 32°F ±(5.0% reading + 5 digits)
32 to 750°F ±(1.0% reading + 3 digits)
Temperature
760 to 1800°F
1°F
±(2.0% reading + 3 digits)
NOTE: Accuracy specifications consist of two elements:
• (% reading) – This is the accuracy of the measurement circuit.
• (+ digits) – This is the accuracy of the analog to digital converter.
NOTE: Accuracy is stated at 64
o
F to 82
o
F (18
o
C to 28
o
C) and less than
75% RH ambient MultiMeter conditions.
Diode Test Test current of approximately 1mA, open circuit
voltage 2.8V DC typical
Continuity Check Audible signal will sound if the resistance is
less than approximately 40Ω, open circuit
voltage 2.8V DC typical
Temperature sensor Type K temperature probe
Input Impedance 10MΩ (VDC and VAC)
Display 2000 count LCD
Overrange indication “1” is displayed
Polarity Automatic (no indication for positive polarity);
Minus (-) sign for negative polarity.
Measurement Rate 0.4 seconds, nominal
Low Battery Indication “ ” is displayed if battery voltage drops
below operating voltage
