Craftsman 82170 - Symbols and Annunciators; Specifications

6
SYMBOLS AND ANNUNCIATORS
Continuity
Low Battery
Diode
H Data Hold
AC Alternating Current or Voltage
DC Direct Current or Voltage
SPECIFICATIONS
Function Range Resolution Accuracy
200mV 0.1mV
±(0.5% reading + 1 digit)
2V 1mV
20V 10mV
200V 100mV
±(0.5% reading + 3 digits)
DC Voltage
(V DC)
1000V 1V
±(0.8% reading + 3 digits)
2V 1mV
20V 10mV
200V 100mV
±(1.0% reading + 5 digits
AC Voltage
(V AC)
(40 - 400Hz)
700V 1V
±(1.2% reading + 5 digits
2mA
1µA
20mA
10µA
±(1.0% reading + 3 digits)
200mA
100µA ±(1.5% reading + 5 digits)
DC Current
(A DC)
20A 10mA
±(2.0% reading + 10 digits)
2mA
1µA ±(1.2% reading + 5 digits)
200mA
100µA ±(2.0% reading + 5 digits)
AC Current
(A AC)
(40 - 400Hz)
20A 10mA
±(3.0% reading + 10 digits)
200Ω 0.1Ω ±(1.0% reading + 10 digits)
2kΩ 1Ω
20kΩ 10Ω
200kΩ 100Ω
2MΩ 1kΩ
±(1.0% reading + 1 digit)
Resistance
20MΩ 10kΩ ±(1.0% reading + 5 digits)
