GROUND SPEED CONTROL LEVERS
LEVER HEIGHT AND ANGLE OPTIONS
Note: The bolts need to be spaced so there is a hole
open (a) in between.
a
a
a
13 lb-ft
(18 Nm)
13 lb-ft
(18 Nm)
Check Tire Pressure
Tires are over-infl ated for shipping purposes.
The maximum inflation is stamped on the sidewall of
the tires. Do not exceed the maximum tire pressure.
Check Oil Level (a)
Fuel (b)
Note: Engine is shipped with oil, however, oil should be
checked prior to use.
• Tractor should be on a level surface.
• Check that the engine is fi lled to full mark on
dipstick.
• See Operator's Manual for complete instructions.
and oil recommendations.
Fill the fuel tank with fresh gasoline. See Engine
Operator's Manual for complete instructions. and
gasoline recommendations. .
b
a
WARNING
