5
Mower Leveling
PREPARATION
WARNING
For your personal safety, do not handle the sharp
mower blades with bare hands. Careless or
improper handling of blades may result in serious
injury.
See Operator's Manual for complete control panel
instructions.
SIDE-to-SIDE LEVELING
Arrange the blades so they are pointing from side-to-
side. Using a measuring tool, measure the distance
between the the ground and the outside tips (a, b) of
each blade.
The diff erence should be: less than 1/8˝ (3mm).
IF AN ADJUSTMENT IS NEEDED:
Tighten / loosen nuts (c) (right and left side) as needed
to adjust side-to-side leveling.
a
b
c
c
Park tractor on a hard level surface and
turn wheels straight.
Check tires for the correct pressures.
Place mower approximately in the middle
height of cut position.
Disengage mower blades.
Set parking brake.
Turn ignition OFF and remove key.
Disconnect spark plug wires and place
away from plugs.wheels straight.
en
