5. Ensure the chain is properly set in the slot around the
entire guidebar.
6. Place the saw chain around the sprocket
18
. While
lining up the slot on the guide bar with chain tensioning
pin
19
, and the bolt
20
, on the base of the tool as
shown in Fig.F.
7. Once in place, hold the bar still, replace sprocket
cover
6
. Install the rear of the sprocket cover first, rotate
it down and make sure the bolt hole on the cover lines
up with the bolt
20
, on the mainhousing.
8. Install the bar lock nut
7
and rotate clockwise with the
hex wrench
16
provided
until snug
, then loosen nut one
full turn, so that the saw chain can be properlytensioned.
9. Rotate the chain tensioning screw
8
clockwise to
increase tension as shown in Fig.E. Make sure the saw
chain
5
is snug around the guide bar
4
. Tighten the bar
lock nut
7
untilsnug
.
10. Follow the instructions in the section Adjusting
ChainTension.
Adjusting Chain Tension (Fig. A, E–H)
WARNING: Incorrect saw chain tension can cause the
saw chain to come off of the guide bar and could cause
serious injury or death.
NOTE: Saw chain tension should be adjusted regularly
before eachuse.
1. With the saw still on a firm surface check the saw
chain
5
tension. The tension is correct when the saw
chain snaps back after being pulled 1/8" (3 mm) away
from the guide bar
4
with light force from the middle
finger and thumb as shown in Fig.G. There should be no
“sag” between the guide bar and the saw chain on the
underside as shown in Fig.H.
2. To adjust saw chain tension, loosen bar lock nut
7
.
3. Rotate the chain tensioning screw
8
in the front of
the housing using the flat screwdriver end of the
hex wrench
16
.
4. Check saw chain tension, adjust ifneeded.
5. Do not over-tension the saw chain as this will lead to
excessive wear and will reduce the life of the guide bar
and saw chain. Overtensioning also reduces the amount
of cuts you will get per batterycharge.
6. Once saw chain tension is correct, tighten bar lock nut
7
untilsnug
. Torque the bar lock nut
7
to 6 ft-lbs (8 Nm).
7. A new chain stretches slightly during the first few hours
of use. It is important to check the tension frequently
(after disconnecting battery remove the battery pack)
during the first twohours ofuse.
Installing the Guide Bar and Saw Chain
(Fig. A, E–I)
CAUTION: Sharp chain. Always wear protective gloves
when handling the chain. The chain is sharp and can
cut you when it is notrunning.
WARNING: Sharp moving chain. To prevent accidental
operation, ensure that battery is removed from the tool
before performing the following operations. Failure to
do this could result in serious personalinjury.
If the saw chain
5
and guide bar
4
are packed separately in
the carton, the chain has to be attached to the bar, and both
must be attached to the body of thetool.
1. Place the saw on a flat, firmsurface.
2. Rotate the bar lock nut
7
counterclockwise with the hex
wrench
16
provided.
3. Remove sprocket cover
6
, and bar lock nut
7
.
4. Wearing protective gloves, grasp the saw chain
5
and
wrap it around the guide bar
4
, ensuring the teeth are
facing the correct direction (Fig.I).
Replacing the Saw Chain (Fig.E, I)
WARNING: Sharp moving chain. To prevent accidental
operation, ensure that battery is removed from the tool
before performing the following operations. Failure to
do this could result in serious personalinjury.
CAUTION: Sharp chain. Always wear protective gloves
when handling the chain. The chain is sharp and can
cut you when it is notrunning.
CAUTION: The chain speed of this product is 8.6 m/s.
Only use chains that are rated at greater than 8.6 m/s.
separately) at least 1” (25.4mm) long, with a screw head
diameter of 0.28–0.35” (7–9mm), screwed into wood to an
optimal depth leaving approximately 7/32” (5.5 mm) of the
screw exposed. Align the slots on the back of the charger
with the exposed screws and fully engage them in theslots.
NOTE: Do not attempt to mount CMCB101 charger under a
bench ortable.
NOTE: Only mount CMCB101 charger with the charging
lights pointed upward toward theceiling.
VersaTrack™
WARNING: Do not charge batteries while charger is
hung onTrackwall.
CRAFTSMAN chargers, except the CMCB101, can
be stored on CRAFTSMAN VersaTrack™ Trackwall.
Hooks and accessories are sold separately. Please
refer to the VersaTrack™ Trackwall accessory sheet for
furtherinformation.
NOTE: The CMCB101 charger is not CRAFTSMAN VersaTrack™
Trackwallcompatible.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
ASSEMBLY AND ADJUSTMENTS
WARNING:
To reduce the risk of serious personal
injury, turn unit off and
remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Hex Wrench Storage (Fig.A, S)
When not in use the hex wrench
16
should be stored in the
hex wrench storage
17
area located under the tool.
1. Pull the hexwrench from the hex wrench storage area
to remove it.
2. Push the hex wrench into the hex wrench storage area
to store it.
