SAFETY WARNINGS AND CAUTIONS:
• Use appropriate safety equipment when using power and hand tools. Failure to do so may cause personal injury i
or product damage. |
• Use adequate manpower when assembling and moving this unit. Failure to do so may cause personal injury or |
product damage. |
• DO NOT stand on this product. You may fall which may cause personal injury. |
• DO NOT mount this product on a truck bed or any other moving object. This may cause personal injury or |
product damage. |
• Appropriately secure this product before moving it with a forklift. |
• DO NOT alter this product in any manner. For example, do not weld external Iockbars or attach electrical |
equipment. This may cause product damage or personal injury. |
• Keep the product on level surfaces. The product may become unstable and tip if stored or moved on an un-level i
surface, which may cause personal injury or product damage. |
• Maximum combined weight limit not to exceed 5,000 pounds (Max. of 1,000 pounds per shelf, evenly |
distributed). If the limit is exceeded, the product could collapse and cause personal injury or product damage. J
k.
J
Tools Required: Parts Included: Hardware Included:
7/16" Wrench Label Description Quantity
Hex Key (Included with unit) A Leg, Bottom 3
Square B Side Support 10
Rubber Mallet C Leg, Bottom Front 2
Drill D Leg, Top 3
3/16" Drill bit E Shelf, Corner Unit 4
Socket wrench (optional) F Leg, Top Front 2
7/16" socket (optional) G Top Shelf 1
5/32" Allen socket (optional)
AA(98) DD(10)
BB(30) _ EE(2)
_D (3)
cc(48)
FF(2)
F (2)
!E (4)
A (3)_
C (2)_
H GG
r
HH(2)
Included with your shelving unit hardware is a bag
containing 30 screws and 30 nuts, all BLACK in
color. These screws and nuts are to be used to
secure the shelves to the side rails. These are
included in the hardware counts above. For the
Black and Platinum units all hardware is Black in
color.
Call 1-800-4MY-HOME (1-800-469-4663) for Service Parts.
efer to Service Parts Drawing for full listing of Service Parts.
To Next Page
