Plastic Base
Washer
Screw
POWER SOURCE
INSTALLATION
AC/DC adapter
to the wall outlet having AC 100-240~;50/60 Hz.
Assemble the plastic base to the main body with the supplied screw and washer as
the figure above.
Insert the small plug from supplied AC/DC adaptor to DC IN jack
on the rear of the unit and insert the AC/DC adaptor
Placing on Floor in Vertical
NOTE:This AC/DC adapter is intended to be correctly
operated in a vented indoor wall outlet.
To the DC IN jack on the rear of unit.
