1 DESCRIPTION
1.1 PURPOSE
This machine is used to cut grass, light weeds, and other
similar vegetation at or around ground level. The cutting
plane must be approximately parallel to the ground surface.
You cannot use the machine to cut or chop hedges, shrubs,
bushes, flowers and compost.
1.2 OVERVIEW
Figure 1 - 19.
1
Battery release button
2
Trigger
3
Lock-out lever
4
Speed switch
5
Carrying ring
6
Auxiliary handle
7
Upper shaft
8
Coupler
9
Lower shaft
10
Trimmer head
11
Cut-off blade
12
Guard
13
Blade
14
Knob
15
Release button
16
Positioning hole
17
Knob
18
Lower clamp
19
Bolt
20
Slot
21
Spool cover
22
Line exit hole
23
Tab
24
Spool housing
25
Spool
26
Angle transmission hole
27
Metal rod
28
Nut
29
Outer cup
30
Plate
A
Direction of rotation
B
Best cutting area
C
Dangerous cutting area
1.3 PACKING LIST
1
String trimmer bare
tool
2
Brush cutter blade
assembly
3
Auxiliary handle
assembly
4
Guard assembly
5
Metal rod
6
Shoulder strap
7
Wrench
8
Operator manual
2 SAFETY
WARNING
Make sure that you follow all safety instructions.
Refer to Safety Manual.
3 INSTALLATION
WARNING
Remove the battery pack from the machine before
installation.
WARNING
Do not use accessories that are not recommended for this
machine.
3.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine before
use.
WARNING
• If parts of the machine are damaged, do not use the
machine.
• If you do not have all the parts, do not operate the
machine.
• If parts are damaged or missing, contact the service
center.
1. Open the package.
2. Read the documentation provided in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in compliance with
local regulations.
WARNING
For your personal safety, do not insert battery before the
tool is assembled completely.
3.2 ATTACH THE GUARD
Figure 2.
WARNING
Do not touch the cut-off blade.
