Cramer RM800 - Installing and Connecting the Charging Station

CRAMERTOOLS.COM
9
EN
Version 1 - 2020.12.30
The entire charging station must be inside the operating area as shown
in the figure.
Installation
Position for the charging station as follows:
• In a level spot out of direct sunlight
(The front end of the charging station must not be 5 cm higher or
lower than the back end.)
• Within reach of a wall socket
(The low voltage cable is 10 m long.)
• With at least 3 m in front of it and 1 m to each side
(Do not position in confined spaces in the operating area.)
Installing and Connecting the Charging Station
>1m
>1m
1m
35cm
>3m
10m
