M083.x
Page 2 of 12
TOOLS NEEDED
• Philips Screw Driver
• Scissors or Wire Cutters
• Static Discharge Strap
Coin Insert Assembly DN5800-4 and Keypad upgrade
Part numbers and description
NOTE 1: Keypad membrane revised by adding the graphic overlay to the
membrane.
BevMax 4 Assembly Coin Insert and Keypad CR0002043
Part of Assembly, Coin Insert and Keypad CR0002043
Bracket coin return
button BV4
CR0005650
Spring Compression
80170154
Assembly coin button
return CR0007492
Clip, Richo flat cable
BV4 CR0005752
Chute coin insert
BV3/4 801,823,55x.x1
Keypad Cover BV4 shown
not part of assembly
801,824,62x.x1 see note 3
