key to save and display will show “#### Offset recorded. Then press “CLR to go back to “Shelf Offset”. Go
to Position Test and check the plunger is contacting the targets correctly.
Coke Factory Setup
Position Test Test Delivery Cup to column selected:
This sub menu will be used to test the vend mechanism alignment to specific columns confirming the proper X
belt tension. Note: The left door switch must be pulled to the out position to perform this test. Caution: XY needs
to be in the home position before performing this test. If you look at the control board the green, amber (yellow),
and red lights should be on at this time. If not please check the following: Green light is for home switch on bottom
of port cup, amber (yellow) light is for home switch on left side of Y motor assembly, red light is for home switch
for picker cup plunger. Press the number 4 key and the display will show a set of numbers (i.e. ###### # ######
#). To position test press the following:
a. Shelf letter (A,B,C,D,E) to travel to selected shelf.
b. Column number (1,2,3,4,5,6,7,8, & 9) to travel to selected column.
c. Key “0” to cycle cup plunger to hit column target.
d. Key “F” to return cup to home position.
e. Key ““is all stop.
f. Press “CLR” key to return to “Position Test”.
Coke Factory Setup
Set Hook Offset Test Delivery Cup to Port Alignment:
This sub menu will be used to test the vend mechanism alignment to the port area confirming the proper X belt
tension. Adjust Hook Swipe “X” Offset (left to right). Press the number “4” key and the display will show “Hook
Swipe ####, 3310 counts = 1 inch”. For factory default setting see born on label settings listed on service door.
To change the off set, pull the top left (white) door switch in the out position to power the XY motors. Press the
key once will automatically run the Delivery Cup Assembly to the swipe position and allow specific vender
coordinates to be changed and saved in the control board memory. Use the numbers on the key pad to change
the coordinates. Press the key to save the new setting and the Delivery Cup Assy. will automatically go to
the “Home” position, then move back to the swipe position again. Press the key to send the Delivery Cup
Assy. back to the “Home” position and the programming will return to Set Hook Offset”. Press key 2 to go to
next menu item.
Coke Factory Setup
Cup Sensor On/Off Turns Delivery Cup Sensor On & Off:
This sub menu will be used to set the Cup Sensor On or Off. Press key 4 and the display will show “Cup Sensor
On”. Press the “4” key to toggle the Extended Cup to the On setting. Factory default setting beginning with
software revision 700.21 is on. If there is a problem in the cup the sensor can be turned off. Press key 1 to return
to “Cup Sensor On/Off”.
