Crate continually develops new products, as well as improves
existing ones. For this reason, the specifications and information
in this manual are subject to change without notice.
CA-1P/1PD
Technical Specifications:
©1997 SLM Electronics • A Division of St. Louis Music Co.
1400 Ferguson Avenue • St. Louis, MO 63133
P/N 47-434-02
05/97
Channel One: Low: +/-15dB @ 80Hz
Mid: +/-15dB @ 650Hz
High: +/-15dB @ 10kHz
Input Impedance: 25k ohm (Active), 2.2M ohm (Piezo)
Input Sensitivity: 22mV RMS (Actv), 9mV RMS (Pzo)
Sens. to Eff Send/Line out: 70mV
Max Input Signal: 6v RMS (17v peak to peak)
Feedback Elimination: Freq: variable from 80Hz to 4kHz
Cut: variable from -0 to -30dB
Channel T
wo: Low: +/-15dB @ 80Hz
High: +/-15dB @ 10kHz
Input Impedance: 3k ohm (Lo-Z), 20k ohm (Hi-Z)
Input Sensitivity: 3mV RMS (LZ), 15mV RMS (HZ)
Sens. to Eff Send/Line out: 9mV (LZ), 50mV (HZ)
Max Input Signal: 10v RMS (28v peak to peak)
Effects Loop: Line Out 1v RMS, Line In 1v RMS
Stereo Input:
Input Impedance: 20k ohm to Ch. 2
25k ohm Active to Ch. 1
2.2M ohm Piezo to Ch. 1
Input Sensitivity: 15mV to Ch. 2
22mV Active to Ch. 1
9mV Piezo to Ch. 1
Eff Return to Line Out Sens: 50mV
Eff Return In. Impedance: 11k ohm
Eff Send Out. Impedance: 2.2k ohm
Line Out Out.Impedance: 220 ohm (Lo-Z), 2.2k ohm (Hi-Z)
Ch. 1 Out. Impedance: 10k ohm
Ch. 2 Out. Impedance: 10k ohm
Power Requirements: 120VAC, 60Hz, 14VA;
100/110VAC, 50/60Hz, 14VA;
230VAC, 50/60Hz, 14VA
Size and Weight: 1-3/4”H x 19”W x 7-5/8”D,
9 lbs.
