The
GT-80DSP
Front
Panel
-
Con
't:
*
*
*
Please
refer
to
the
illustration
on
page
4.
*
'
*
17:
MID:
Adjust
the
Rhythm
Channel's
midrange
output
with
this
control:
in
the
center
position
the
midrange
out¬
put
will
be
'flat”
(no
boost
or
cut).
Turning
the
control
to
the
left
reduces
the
midrange
output;
turning
it
to
the
right
increases
the
midrange
outpul.
The
Mid
control
provides
up
to
7dB
of
boost
or
cut
centered
at
800Hz.
which
affects
the
'voice'
of
your
guitar’s
sound.
18:
HIGH:
Adjust
the
Rhythm
Channel's
high
frequency
output
with
this
control:
in
the
center
position
the
high
frequency
output
v/ill
be
“flat"
(no
boost
or
cut).
Turning
the
control
to
the
left
reduces
the
high
frequency
output:
turning
it
to
the
right
increases
the
high
frequency
output.
The
High
control
provides
up
to
15dB
of
boost
or
cut
centered
at
10kHz,
which
albws
you
to
adjust
the
crispness
or
the
'bite'
of
your
guitar.
19:
RHYTHM
LED:
This
LED
glows
green
when
the
Rhythm
Channel
is
chosen,
and
along
v/ith
LCD
#9,
gives
you
a
visual
sign
that
the
Rhythm
channel
is
active.
20:
LEVEL:
Adjust
the
output
level
of
the
Rhythm
channel
with
this
control:
in
the
full-left
position
there
is
no
out¬
put.
As
you
rolate
the
control
to
the
right
you
increase
the
strength
of
the
Rhylhm
channel's
signal
going
into
the
power
amp.
thus
increasing
the
output
vetume.
The
signal
level
tor
the
Line
Out
jack
(see
#31.
rear
panel)
is
si¬
multaneously
affected
by
this
control.
Ibe
Digital
Sound
Processor
(DSP):
I
Gtvea
below
is
a
brief
description
of
the
Digital
Sound
Processor's
controls.
For
complete
informa-
||
tion
on
the
use
and
functions
of
the
Digital
Sound
Processor,
please
see
pages
8
through
11.
21:
LED:
This
LED
indicator
glows
when
the
Digital
Sound
Processor
is
active,
indicating
the
presence
of
a
pro¬
cessed
signal
22:
MODE:
Select
the
type
of
digital
sound
processing
effect
with
this
control.
Each
preamp
and
channel
setting
will
'remember'
its
setting,
allowing
you
to
switch
between
channels
and
preamps
(Tube'Sotid
State)
williout
hav¬
ing
to
reset
the
Mode
control.
Fora
complete
listing
of
the
different
effects
and
their
corresponding
settings,
see
"Usiag
the
Mode
Control"
on
page
8.
23:
LEVEL:
Adjust
the
amount
of
digital
sound
processing
effect
with
this
control:
in
the
full-left
position
the
out¬
put
signal
is
“dry'
(no
revert
or
effect);
rolating
the
control
to
the
right
increases
the
amount
ot
ettect.
24:
ON
LED:
The
word
'ON"
will
glow
red
when
you
turn
tho
GT
GODSP
on.
showing
you
that
the
amplifier
is
ac¬
tivated
and
ready
to
play.
25:
POWER:
This
heavy-duty
rocker-type
switch
is
used
to
turn
the
amplifier
ON
in
the
left
position.
OFF
in
the
right
position.
The
ON
LED
(#24)
works
with
this
switch
as
a
visual
indicator.
