Crate V50-112 User Manual

V50-112 Tube Guitar Amplifier with Reverb
11
Declaration Of Conformity
Manufacturer: LOUD Technologies Inc.
16220 Wood-Red Rd. NE
Woodinville, WA 98072, USA
Product Name: Crate V50-112
Product Type: Audio Amplifier
Complies with Standards:
LVD: 92/31/EEC, 93/68/EEC, & 73/23/EWG
Safety: EN60065
EMC: EN55013, EN55020, EN55022, EN55103, EN61000-3-2,
& EN61000-3-3
The official Declaration of Conformity for this product is kept on file at:
LOUD Technologies Inc., 16220 Wood-Red Road NE, Woodinville, WA 98072 • Tel: 1-866-858-5832
System Block Diagram
GUITAR
INPUT
OVERDRIVE
GAIN
REVERB
LEVEL
REVERB
IN
8 OHM
INTERNAL
SPEAKER
EFFECTS
SEND
EFFECTS
RETURN
REVERB
OUT
CLEAN
VOLUME
OVERDRIVE
LEVEL
CHANNEL
SELECT
12AX7A
V1A
12AX7A
V1B
12AX7A
V2A
12AX7A
V2B
CHANNEL
SELECT
PHASE
SPLITTER
6L6GC
6L6GC
12AX7A
V3A
12AX7A
V3B
BASSTREBLE MID
BOOST
PRESENCE
8 OHM
EXTENSION
SPEAKER

Crate V50-112 Specifications

General

Brand	Crate
Model	V50-112
Category	Amplifier
Language	English
