V50-112 Tube Guitar Amplifier with Reverb
12
www.crateamps.com
@2007 LOUD Technologies Inc.
16220 Wood-Red Road NE • Woodinville, WA 98072
Part No. 0024425 Rev. A1 04/07
V50-112 TECHNICAL SPECIFICATIONS
Output Power Rating 50 W rms @ 5% THD, 8 ohm load, 120 VAC
Signal-to-Noise Ratio 70 dB, Typical (Clean Ch only)
Gain Overdrive Ch 98 dB, all controls @ 10
Clean Ch 58 dB, all controls @ 10
EQ Treble: 12 dB range @ 6 kHz
Middle: 10 dB range @ 1 kHz
Bass: 8 dB range @ 150 Hz
Boost 10 dB @ 900 Hz
Presence 8 dB range @ 10 kHz
Speaker Specs 12", 50 W, 8 ohm, 1.75" voice coil diameter,
30 oz magnet
Extension Speaker 8 ohms minimum nominal impedance
Preamp Tubes (3) 12AX7A
Power Tubes (2) 6L6GC
Power Requirements 90-132 VAC, 60 Hz, 150 VA
220-240 VAC, 50 Hz, 150 VA
Size (H x W x D) 19.0 in/48.3 cm x 24.0 in/61.0 cm x
11.0 in/27.9 cm
Weight 48.5 lb/22.0 kg
The V50-112 is covered with a durable fabric-backed vinyl material. Wipe it clean with a lint-free cloth.
Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
Crate continually develops new products, as well as improves existing ones. For this reason, the specifications
and information in this manual are subject to change without notice.
“Crate” is a registered trademark of LOUD Technologies Inc. All other brand names mentioned are trademarks or
registered trademarks of their respective holders and are hereby acknowledged.
Service Information
If you are having a problem with your V50-112, you can go to our website (www.crateamps.com)
and click on Support for service information, or call 1-800-898-3211 during business hours
(7
am to 5 pm PST, Monday-Friday). If you are outside of the U.S., contact your local distribu-
tor for technical support and service.
