CRAWLER ANKA300 - Using the ANKA300; Opening the Rear Vehicle Door; Opening the Rear Entry Door

CRAWLER
Model: ANKA 300
Version: EN 1.00.0922
12
Use of ANKA300
1. Opening the Rear Vehicle Door
Before opening the rear entrance door of ANKA300, set the
vehicle's tailgate to the horizontal position. Insert the
ladder into the fixing bracket on the cover.
2. Opening the Rear Entry Door
Top Lock
Turn the upper lock entry in the horizontal position (1)
counter-clockwise to the vertical position and remove it.
(2)
Bottom Lock
(3) Turn the vertical lower lock hub clockwise.
(4) After the lock bolt is in, turn the key back to the vertical
position and remove it.
Make sure the floor is flat and not slippery.
It is recommended to install the fixing device on
the tailgate.
Before using the ladder, make sure it snaps into the fixing
bracket.
