Right Swing Door is Shown.
Push in (8) Connecting Bolts into
predrilled holes in RB Swing Lid
and LB Swing Base as shown.
Push in (4) Connecting Bolts into
predrilled holes in RS1 and RS2
as shown.
1
Connecting Bolts (4)
Connecting Bolts (4)
RS Lid
RS Base
RS Side
RS Side
