ENGLISH
• To avoid personal injury and injury, make sure that the place where you are going to hang
the fan allows the blades to be 2.3 m or more from the ground and 76 cm from the nearest
wall or obstacle.
• Make sure the junction box is adequately fastened to the building structure and can sup-
port the full weight of the fan.
INSTALLATION PREPARATION
Before installing the mounting bracket you should check the ceiling where the fan is to be
installed and check if it is suitable for it.
INSTALLING THE MOUNTING BRACKET
Concrete ceiling
Drill 2 holes with an 8mm drill bit, accord-
ing to the length of the expansion bolts.
Next, x the mounting bracket to the ceil-
ing with the screws.
Wood roof
Attach the mounting bracket to the wood
ceiling with 4 minimum 7mm thick screws.
Do not x the mounting bracket directly on ceilings less than 10mm to avoid the risk of the
screw loosening and coming out.
76 cm76 cm
2.3 m
