Overview
1. Power button / Battery Status Indicator
2. Volume -
3. Volume +
4. Bluetooth
®
Button / Status Indicator
5. Source Button
6. NFC touchpoint
7. Source Indicator
8. Button / Status Indicator
9. Equalizer Status Indicator
10. Previous Button
11. Next Button
12. Play / Pause Button
13. Record Button / Recording Status Indicator
14. (Record) Play / Pause Button
15. MP3/FLAC Shuffle Button / Shuffle Playback
Indicator
16. MicroSD Slot
17. Micro USB Connector
18. DC Out (USB 1.0A) / USB Flash drive Connector
19. Aux-In / External Microphone In
20. 15V DC In
21. Microphone
Front Top
2 4
1 3 5 76
8
17
16
18
19
20
4
9
10
11
13
14
12
15
IPX6 (IEC 60529)
4
21
