Connecting Audio Control Module
The ACM accessory is bundled with Sound Blaster Zx only.
Connecting your ACM to the Sound Blaster Z-Series
Jack, Connector or Cable Description
1. Line In/Microphone In jack
Connects to the 3.5mm (1/8-inch)
microphone plug of your ACM.
2. Headphone jack Connects to your ACM with a 3.5mm
(1/8-inch) plug.
Connecting Speakers and Headphones 17
